High Performance and Non-Rotating Crane Ropes

Bridon Crane ropes offer strength and superior quality providing our customers with considerable cost savings, in addition to the peace of mind of working with a world leader.

When selecting a steel wire rope to suit a particular application - strength, rotation and fatigue resistance should be taken into consideration. Standard features you can expect from a Bridon crane rope.

  • Superior bending fatigue life when compared with conventional low rotation ropes - proven by laboratory testing and extensive field experience.
  • Excellent resistance to crushing and abrasion resulting from the overall compactness and robustness of the rope and the Dyform strands - recommended when multi-layer spooling is involved.
  • Reduced elongation resulting from increased steel content and the Dyform process.

Applications

  • Container Crane
  • Crane Boom Hoist
  • Crane Jib Hoist
  • Crane Pendants
  • Crane Trolley
  • Excavators
  • Gantry Cranes
  • Hoist Rope
  • Mobile Cranes
  • Overhead Cranes
  • Ship Ramps
  • Shovels
  • Skip Hoist
  • Tower Cranes
  • Truck Cranes






A selection of the many types of non-rotating high performance wire ropes are available:

Wire Rope Endurance 35LS Dyform 6 Endurance 50DB Dyform 34LR
Nom. MBF (kN) MBF (kN) MBF (kN) MBF (kN)
Dia.



mm
Rope Grade


1960 (MPa)
Rope Grade


2160 (MPa)
Rope Grade


1960 (MPa)
Rope Grade


2160 (MPa)
Rope Grade


2160 (MPa)
Rope Grade


1960 (MPa)
Rope Grade


2160 (MPa)
10 75.4 86 85 91.5 86 90 98
11 90.6 104 98 113 104 109 118
12 106 124 114 127 124 130 140
13 127 145 147 157 145 154 166
14 147 167 169 183 168 179 191
15 170 190 - - 190 205 220
16 193 220 - - 220 232 251
17 - - 245 270 240 260 284
18 241 275 275 298 275 298 319
19 275 310 302 323 310 329 356
20 - - 333 355 335 370 397
21 333 368 - - 368 400 432
22 368 410 398 423 410 442 482
23 398 446 - - - 480 525
24 439 495 487 518 - 528 569
25 471 534 - - - 572 620
26 514 578 576 610 - 618 658
27 - - - - - 662 718
28 596 677 655 700 - 716 784
30 - - 755 806 - 823 900
32 765 861 844 914 - 940 1030
36 - - 1060 1120 - 1180 1280
