NGK Wire Grips

1 tonne L-Grip

Uses:

For bare copper cable, covered conductor and messenger wire.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
10kN (1.0t) 4 22 1.1

AL- Middle - Grip

Uses:

For bare aluminum cable, and bare copper cable.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
20kN (2.0t) 5 25 1.8

2 tonne L-Grip

Uses:

For bare copper cable, covered conductor and messenger wire.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
20kN (2.0t) 4 22 1.3

AL- Large - Grip

Uses:

For bare aluminum cable, and bare copper cable.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
20kN (2.0t) 16 32 2.0

3 tonne Grip

Uses:

For wire rope, messenger wire, copper cable and trolley cable.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
30kN (3.0t) 8 22 3.0

2 tonne W-Grip

Uses:

For wire rope, messenger wire, copper cable and trolley cable.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
20kN (2.0t) 5 16 1.4

4 tonne Grip

Uses:

For wire rope, messenger wire, copper cable and trolley cable.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
40kN (4.0t) 13 28 5.0

SD L-Grip

Uses:

For steel rod, copper cable and messenger wire.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
10kN (1.0t)) 2.6 15 0.6

Middle L - Grip

Uses:

For copper cable, covered conductor and messenger wire.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
20kN (2.0t) 5 25 1.8

ABC Grip

Uses:

For aerial bundled cable
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
8.5kN (0.85t) 4 x 35 4 x 95 3.0

Large L-Grip

Uses:

For copper cable and covered conductor.
Safe Working Load Min. Cable Dia. mm Max. Cable Dia. mm Weight kg
20kN (2.0t) 16 32 2.1
